MetriScan Finger Bone Densitometer

Medical Device Name

12-Channel Automatic Electrocardiograph

Basic Information

Brand: Fukuda Electronics
Model: FX-7402
Date of Manufacture: July 2014
Manufacturer: Beijing Fukuda Electronics Medical Instrument Co., Ltd.
Condition: Pre-Owned
Availability: In Stock

Display & Acquisition

• 5.6-inch LCD touch display with backlight

• Twelve-lead synchronous acquisition and recording, standard 12-lead recording

Electrical Performance

• Input impedance: >50 MΩ (10 Hz)

• Input circuit current: <50 nA

• Frequency response: 0.05–150 Hz (-3 dB)

• Gain: 1/4, 1/2, 1, 2 cm/mV, manual or automatic

• Common mode rejection ratio (CMRR): >103 dB

• Anti-polarization voltage: >550 mV

• Defibrillation protection with anti-defibrillation function

• Time constant: 3.2 seconds (0 ~ +20%)

Signal Processing

• Filters: AC, EMG, baseline drift, high-frequency, and low-frequency filters

• A/D resolution: 18-bit

• Sampling rate: 8000 samples/sec/channel

Recording & Printing

• Recording speed: 5, 10, 12.5, 25, 50 mm/s ±3%

• Thermal print head resolution:

  • Vertical: 8 dots/mm

  • Time axis: 1 ms

• Recording channels:

  • 3-channel

  • 3+1 (rhythm lead)

  • 3+2 (rhythm lead)

  • 6-channel

  • 6+1

  • 12-channel

• Recording paper: 210 mm wide roll paper (A4)

• Recording method: Built-in thermal array recorder, supporting automatic, manual, measurement, and analysis recording

• Capable of printing ECG waveforms, measurement values, and analysis/diagnostic reports, including:

  • Rhythm analysis report

  • Arrhythmia analysis report

  • ST segment quantitative analysis report

  • RR interval histogram and trend graph

Advanced Recording Functions

• Record review: Playback of 24-second measured ECG waveforms or review of 10-second ECG waveforms

• Post-exercise recording: Ability to record ECG waveforms after exercise or medication

• Automatic arrhythmia extended recording: During analysis, when arrhythmia is detected, the system automatically prints an arrhythmia ECG report

Storage & Interfaces

• Storage capacity: Main unit can store more than 300 sets of ECG data

• Output display: Supports connection to a secondary display

• Serial interface: Built-in RS-232C serial interface module (optional PC software)

Optional Functions

• Optional PC card support, capable of storing several thousand ECG data records

• Supports software upgrades
